AIR INLET

• 1/2" FNPT

LIQUID INLET

• 51 mm (2")

LIQUID DISCHARGE

• 51 mm (2")

CONNECTION TYPE

• NPT/BSPT (Threaded)

MAX SUCTION LIFT CAPABILITY

• Rubber –6.9 m (22.7') Dry, 8.6 m (28.4') Wet
• TPE – 6.7 m (22.1') Dry, 8.6 m (28.4') Wet
• Full-Stroke PTFE – 6.7 m (22.1') Dry, 9.0 m (29.5') Wet
• Reduced-Stroke PTFE – 4.6 m (15.0') Dry, 9.5 m (31.0') Wet
• Ultra-Flex™ – 4.9 m (16.0') Dry, 8.8 m (29.0') Wet

MAX FLOW RATE

• Rubber – 623 lpm (165 gpm)
• TPE – 630 lpm (166 gpm)
• Full-Stroke PTFE – 618 lpm (163 gpm)
• Reduced-Stroke PTFE – 496 lpm (131 gpm)
• Ultra-Flex™ – 526 lpm (139 gpm)

MAX PRESSURE

• 8.6 bar (125 psi)

MAX DIAMETER SOLIDS

• 6.4 mm (1/4'')

DISPLACEMENT PER STROKE *

• Rubber – 2.6 L (0.70 gal)
• TPE – 2.8 L (0.75 gal)
• Full-Stroke PTFE – 2.6 L (0.70 gal)
• Reduced-Stroke PTFE – 1.67 L (0.44 gal)
• Ultra-Flex™ – 2.12 L (0.56 gal)
